Brand: Vuon | SKU: EVRPRO09
VUON EVR 9-Channel is a compact, enterprise-ready Edge Video Recorder designed for reliable recording, storage, playback and remote management of IP camera systems. It brings multi-camera …
Read moreVUON EVR 9-Channel is a compact, enterprise-ready Edge Video Recorder designed for reliable recording, storage, playback and remote management of IP camera systems. It brings multi-camera recording, smart playback, flexible retention policies and secure remote access together in a dedicated edge appliance.
Connect and manage up to 9 IP cameras from a single VUON EVR, making it suitable for offices, retail stores, schools, warehouses, institutions and other small-to-medium surveillance deployments.
Keep surveillance footage securely stored at the edge with support for AES-256 encryption, helping protect recorded video and sensitive surveillance data.
Efficient video compression using H.265 / H.264 helps optimize storage utilization while maintaining video quality.
Supports recording resolutions of up to 16MP, subject to camera compatibility and system configuration.
Quickly locate recorded footage using multiple search parameters including:
Review recorded footage efficiently with multiple playback options designed to make incident investigation faster and easier.
Configure recording and retention policies according to your surveillance requirements, allowing organizations to manage available storage efficiently.
Access your surveillance system remotely through supported:
VUON EVR supports secure cloud-connected video workflows, providing an additional option for remote access and video management.
VUON EVR is designed around an edge-first recording architecture, keeping video recording close to the cameras while providing centralized access and management.
IP Cameras → VUON EVR → Local Storage → Web / Mobile / CMS / Cloud
This architecture helps organizations maintain local recording while enabling convenient remote monitoring and management.
| Feature | VUON EVR 9-Channel |
|---|---|
| IP Camera Support | Up to 9 IP Cameras |
| Video Compression | H.265 / H.264 |
| Maximum Recording Resolution | Up to 16MP* |
| Audio | Camera-dependent |
| Recording | Continuous / configured recording policies |
| Playback | Smart Playback |
| Search | Date / Time / Event / Camera |
| Storage | Local HDD / SATA-based storage* |
| Remote Access | Web / Mobile App / Windows CMS |
| Cloud | Supported |
| Data Security | AES-256 Encryption |
| Network | IP Network |
| ONVIF | Supported* |
*Final specifications should be confirmed against the exact 9-channel hardware configuration before publishing as a guaranteed specification.
| Network | 10/100/1000 Mbps LAN |
| Storage | Supports up to 6TB HDD (Expandable) |
| USB Ports | 2 × USB 2.0 |
| Dimensions | 240 × 150 × 70 mm (Approx.) |
| Power Supply | 12V DC |
| Channel Support | Up to 9 IP Cameras |
| Power Consumption | < 30W |
| Video Compression | H.265 / H.264 |
| Recording Resolution | Up to 8MP |
| Operating Temperature | 0°C to 70°C |
